Self-clinching pilot pins

Pin d₁ ±0.05

6 mm

Min. sm

1.0 mm

L ±0.4

12 mm

Hole-Ø in the sheet
+0.08
  0

6.5 mm

Material

Passivated grade 18/8 stainless steel (AISI 300).

3D-Data available

Download

Application

Unthreaded chamfered self-clinching pilot pins.

Order description

TPS-6MM-12

d₂ ±0.15

4.24 mm

d₃ ±0.4

8.13 mm

Max. a

2.29 mm

Min. edge distance up to the hole centre

7.9 mm

Use

For sheet hardnesses up to HRB 70.

Tools

Identify order numbers of PEMSERTER® tools (anvils and punches): Tooling Selector

Insertion machines

Further information

• Performance tests set up
• PEM® Trademark
• Description/ Installation instructions
• Anvil dimension
